HOSHIZAKI 24KG BALL ICE MAKER - IM-65NE-Q
CHILL BEVERAGES WITH MINIMAL DILUTION
The Hoshizaki IM-65NE-Q is a self-contained under counter ice maker producing clean, pure and perfectly round Ball Ice. It is suitable for placement in bars. Produces up to 20kg per 24 hours and has a storage capacity of 17kg.
Required Water Filter Kit when purchasing this Ice Maker:
Water Filter Kit 75 - 81000116-87000104 (Sold Separately)
Features
- Easy maintenance, low water and energy consumption.
- Each ice ball individually made by a jet spray.
- Automatically drains and refills after each new batch, for fresh, hygienic ice.
- Easily dismantled for cleaning.
- Hoshizaki ice makers are micro computer controlled, controlling the ice making process to perform at its best under varying circumstances, without having to make physical adjustments.
- A stainless steel exterior provides a hygienic and high quality finish.
- closed water circuit for ultimate contamination protection.
- An easily cleanable air filter allows end users to carry out a routine cleaning schedule, extending product life expectancy and reducing the frequency and costs of maintenance call-outs.
- Foam injected polyurethane for insulation (JFC free), helps preserve the quality and consistency of the ice produced, reducing the number of production cycles.
- Warranty: 3 year parts and labour warranty on entire unit, 5 year (parts only) on compressor & air cooled condenser coil.
Technical Specifications
- Max Storage Capacity: Approx. 17kg (Bin Control Setting Approx. 9 kg)
- Freeze Cycle Time: Approx. 33 Min
- Ice Production Per cycle: Approx. 0.67kg/15pcs
- Width Depth Height: 633mm x 506mm x 950mm (Includes 90mm-125mm Legs)
- Weight Net - 53kg
- AC Supply Voltage: 1 PHASE 220-240V 50Hz / 10 AMP Plug
- Amperage: Running: 2.9A, Rated: 2.9A, Starting: 17A
- Refrigerant Charge: R134a / 200g
Operating Conditions:
- Ambient Temp.: 1-40°C
- Water Supply Temp.: 5-35°C
- Water Supply Pressure: 0.07-0.8MPa (0.7-8bar)
- Voltage Range: Rated Voltage ±6%
For more information: To view ice sizes, water inlet/drainage diagram, etc., please download the spec sheet available in the "Downloads" Tab.
